Tubular Tower Section Fabrication 8m Gantry Welding Platform Multi Circular Joint Station

Brief introduction:

• Gantry welding platform with multiple circular seam joint automatic welding station suitable for section diameter range upto 8m;

• Specially using for heavy duty tubular out circle seam welding like monopile, transition piece, wind tower, bullet tank and so on.

Feature:

• Ideal solution for welding multiple joints simultaneously, highly boosting working efficiency, shorten heavy tubular section fabrication time largely.

• The working platform height is vertically adjustable suitable for different diameter section fabrication.

• Welding station is able to use various kinds of welding method such as single wire / tandem twin SAW and so on.

• Complete & considerate safety measure, including safety fence, anti-fall device, anti turn-over device & whole electric safety measure.

• It can replace 2 to 3 welding column and boom welding manipulator.

Technical parameters :

Description:

• Gantry welding manipulator is used to manipulate the welding kits. It is able to position the weld torch to required position for welding in a stable and secure manner.

• Gantry adopts square pine and channel steel structure, process stress relieving, with strong and stable structure.

• Each of walking beams is driven by a motor reducer, forming a double-drive system, which makes the operation smooth and reliable.

• Flux recovery system is optional as per choice. Welding seam tracing, monitoring & other accessories available as per choice.

• The electric control system consists of one electric control box and pendant controller

What Ronniewell can do for Ronniewell customers:

• Give you high quality products.
• Give you five-star price.
• Give you suitable recommendation.
• Give you good after-service.
• Give you professional technical guide.
• Warmly welcome you visit our factory.

Points you may concern:

Customization - Can your machine or other products be customized?
Ronniewell: Sure. As a professional manufacturer, we have our own engineer team, who is good at design, develop & build special solution catering for your individual requirement.

Transportation-What about the transportation?
Ronniewell: Seaway is the most common transportation way for oversea trading. Depends on your location, combined transport by rail and sea is also an option. Certainly railway transportation is also acceptable if it is the most suitable approach.

After sale service - What about the after-sale service?
Ronniewell: We provide 12month guaranty period for the whole machine quality. During this time, any issue proved because of the machine flaw itself,we would take the whole responsibility of it. Except of the guaranty period,technical advisory support is available freely covering the whole using life of the machine. Engineer service on user premises is also available for necessary.

Video link

https://www.youtube.com/c/RonniewellAutomatedWeldingSolutionProvider

Welcome to follow us on following social media:

Facebook: https://www.facebook.com/weldingrotatorcn

LinkedIn: https://www.linkedin.com/in/automatedwelding

Product name:
pipe welding booms, column boom pipe welding booms, CaB, pipe welding booms boom,automatic welding machine, pipe welding booms, cross beam column, welding manipulator;

Ronniewell established since 2007 .We have built our expertise through years of experience. This enables us to produce equipment suitable for almost the entire spectrum of industrial welding and cutting needs.

Ronniewell's range of activities includes consultation, design, manufacture, install and provision of services mainly to Oil & Gas Installations, Constructors and Heavy Engineering and Steel Structure Fabricators.

Comprehensive range for sale:

• CNC flame/plasma cutting machine;
• Welding Rotators, Welding Turning Rolls;
• Welding Positioners & Welding Head and tail stocks;
• Welding Column & Boom Manipulators;
• Horizontal turntables;
• Welding Fit Up rotator & Growing Lines;
• Specialist handling welding rotators & welding positioners for Riser Lines, Pipe Shops, Pile Racks, Double Jointing, and Wind tower Production solutions.
• H-beam production lines;
• Edge milling machine.

Our vision is based on a long term strategy. This means that we are increasing our design and production capacity and we are strengthening our sales and after sales team to be able to serve you in the best possible way.
